Features Specification Standard Kit and Accessories Strips

i-QARE DS-5 Ergonomic elevation design for easy to hold and use 250 Test Memories with Data Display 6 Seconds Reaction Time 1.0 µl (0.001 cc) Blood Volume Ergonomics Large LCD Antimicrobial treatment Specification 1. Dimension: 94mm x 53mm x 17mm 2. Weight: 50g 3. Power Source: CR2032 3V Lithium coin battery x 1 4. Battery Life: Over 1,000 determinants 5. Display: Large LCD 6. External Output: RS232 PC interface 7. Memory: 250 measurement results with date and time 8. Auto electrode inserting detection 9. Auto sample loading detection 10. Auto reaction time count-down 11. Sleeping mode: Power consumption less than 20uA 12. Auto turn-off after one minute without action 13. Temperature warning 14. Operation condition: 14°C ~ 40°C (57.2°F ~ 104°F) 15. Storage/Transportation Condition: -10°C ~ 60°C (14.2°F ~ 140°F) < 95% R.H. 16. Measurement Units: in mg/dL or mmol/L Standard Kit Contents 1. i-QARE Blood Glucose Meter x 1 2. CR2032 3V Battery x 1 3. Lancet Device x 1 4. Wallet x 1 5. User's Manual x 1 6. First Time or Quick Reference Guide x 1 Supplies and Accessories 1. Draw-In Glucose Test Strips 2. Lancet Device 3. Lancets 4. Battery for Device Test Strip Specifications 1.Strip Size: 35mm x 7mm x 0.35mm 2. Required: 1µl (0.001cc ) 3. Test Result Time: 6 seconds 4. Hematocrit: 30%~55% 5. Sample Type: Fresh capillary whole blood 6. Test Range: 20 ~ 600 mg/dL or 1.1~33.3 mmol/L 7. Operation Condition:14°C ~ 40°C (57.2°F ~ 104°F) 8. Validity can be used within 90 days after opening or within 24 months after the production date 9. Unit of Packaging: 25 strips x 2 vials/box 10. Storage/Transportation Condition 4°C ~ 32°C (39.2°F ~ 89.6°F) <95%R.H. DO NOT REFRIGERATE> Remarks 1. Do not use any expired strips. 2. These strips are only used with this glucose meter. 3. Do not use any blood that has been preserved (e.g. by fluoride). 4. It is not recommended to use this test to new born baby. 5. Taking high-dose vitamin C or having high level of uric acid may     influence the blood glucose level, which may cause inaccurate test    results. 6. Hematocrit above 55% may cause lower blood glucose level. 7. To protect the environment, dispose of the used lancets and strips in appropriate collection sites according to national or local regulations. Avoid other people touching the used lancets or test strip, which may cause cross infection via one's wounds. 8. Keep the test strip vial away from children; the cap is a choking  hazard. In addition, the cap may contain drying agent which can harm the body if swallow or inhale it or may cause skin or eye irritation.
