Feature Specification Standard Kit and Accessories Strips

A-CHECK DS-1 DS-1 Manual Download Adobe Reader German Hospital used only 5 years warranty Ergonomics Large LCD 180 Test Memories with Data Display 10 Second Reaction Time 3.0 µl Blood Volume External output Specification 1. Dimension: 81mm x 53mm x 20mm 2. Weight: 46.5g 3. Power Source: CR2032 3V Lithium coin battery x 1 4. Battery Life: Over 1,000 determinants 5. Display: Large LCD 6. External Output: RS232 PC interface 7. Memory: 180 measurement results with date and time 8. Auto electrode inserting detection 9. Auto sample loading detection 10. Auto reaction time count-down 11. Sleeping mode: Power consumption less than 20uA 12. Auto tum-off after one minute without action 13. Temperature warning 14. Operation condition: 14°C ~ 40°C(57.2°F ~ 104°F) 15. Storage/Transportation Condition: -10°C ~ 60°C(14.2°F ~ 140°F),< 95% R.H. 16. Measurement Units: in mg/dL or mmol/L Standard Kit Contents 1. A-CHECK Blood Glucose Meter x 1 2. CR2032 3V Battery x 1 3. Lancet Device x 1 4. Wallet x 1 5. User's Manual x 1 6. First Time or Quick Reference Guide x 1 Supplies and Accessories 1. Draw-In Glucose Test Strips 2. Lancet Device 3. Lancets 4. Battery for Device
